The genesig q16 qPCR Machine

Category: PCR
Catalog
q16
(Ships in 5-10 business days)

Questions? Contact us

Call (800) 832-2611

arp-guarantee
- +
$0.00
More Information
Product Name The genesig q16 qPCR Machine
Description

The genesig q16
The Worlds Most Affordable qPCR Machine


About The genesig q16


What is the genesig® q16?
The genesig q16 is a revolutionary instrument launched by Primerdesign Ltd. The instrument is designed to accompany the genesig® easy product range which includes kits for more than 500 different DNA testing applications. The q16 is designed to make DNA testing affordable and easy for anyone in any business.

What is DNA testing?
DNA testing is the most sensitive and precise way to detect and quantify the presence of a DNA target. The underlying technology within the genesig q16 is real-time quantitative PCR. The technology has been around for 20 years, but to date has been complex and expensive to perform. The genesig q16 changes all that.

What can I use it for?
The genesig® easy product range includes tests for a massive range of applications:

Food and Water Testing
Veterinary Diagnostics
Human Infectious Disease Screening
Biothreat Detection

Technical Details


Ultra simple software interface
Automated data analysis
No moving parts
Silent operation
Operate from PC, Mac, via network, or stand alone with a USB drive
16 Wells

  • 20ul reaction volume

Peltier thermal control

  • 3°C/s heating
  • 2°C/s cooling
  • Thermal uniformity +- 0.1°C range
  • Thermal accuracy +- 0.25°C

Extraordinary well-to-well reproducibility.
Fig shows 16 individual replicates from one test


LED excitation
CMOS detection
* Compatible with FAM and VIC labels
160mm Height
120mm Diameter
2kg weight
90W power consumption
